| 100% Removal Rating | PSS Series Element Part Number | |||
| 100 Series | AB Series | Cylinder Series | ||
|
2 3⁄8" Diameter Elements With 1" or 1 1⁄2" NPT(5) |
1 1⁄2" Diameter Elements With 1⁄4" NPT(5) |
|||
| 5 | MBS100 ■ PO5 ▲ | AB ■ PO57 ▲ | C-23-● ♦ PO5 | C-14- ★ ♦ PO5 |
| 9 | MBS100 ■ PO9 ▲ | AB ■ PO97 ▲ | C-23-● ♦ PO9 | C-14- ★ ♦ PO9 |
| 13 | MBS100 ■ PH ▲ | AB ■ PH7 ▲ | C-23-● ♦ PH | C-14- ★ ♦ PH |
| 20 | MBS100 ■ PF ▲ | AB ■ PF7 ▲ | C-23-● ♦ PF | C-14- ★ ♦ PF |
| 35 | MBS100 ■ PE ▲ | AB ■ PE7 ▲ | C-23-● ♦ PE | C-14- ★ ♦ PE |
| 55 | MBS100 ■ PD ▲ | AB ■ PD7 ▲ | C-23-● ♦ PD | C-14- ★ ♦ PD |
| Code ▲ | Gasket Option |
| H13 | Nitrile (Std.) |
| H | Fluorocarbon Elastomer |
| J | Ethylene Propylene |
| J7 | Ethylene Propylene for Steam Service |
| Code ■ | Nominal Length (in) | Area (ft2) |
| 1 | 10 | 0.5 |
| 2 | 20 | 1.0 |
| 3 | 30 | 1.5 |
| Code ♦ | Connection |
| 1 | 1⁄4" NPT |
| 4 | 1" NPT |
| 6 | 1 1⁄2" NPT |
| Code ● | Nominal Length (in) | Area (ft2) |
| 06 | 6 | 0.31 |
| 09 | 9 | 0.47 |
| 18 | 18 | 0.9 |
| 19 | 19(5) | 0.98 |
| Code ★ | Nominal Length (in) | Area (ft2) |
| 06 | 6 | 0.2 |
| 09 | 9 | 0.29 |
| 18 | 18 | 0.59 |
100 Series不锈钢粉末烧结滤芯型号：
MBS1003PO5H13 MBS1002PO5H13 MBS1001PO5H13 MBS1003PO9H13 MBS1002PO9H13 MBS1001PO9H13 MBS1003PHH13 MBS1002PHH13 MBS1001PHH13 MBS1003PFH13 MBS1002PFH13 MBS1001PFH13 MBS1003PEH13 MBS1002PEH13 MBS1001PEH13 MBS1003PDH13 MBS1002PDH13 MBS1001PDH13 MBS1003PO5H MBS1002PO5H MBS1001PO5H MBS1003PO9H MBS1002PO9H MBS1001PO9H MBS1003PHH MBS1002PHH MBS1001PHH MBS1003PFH MBS1002PFH MBS1001PFH MBS1003PEH MBS1002PEH MBS1001PEH MBS1003PDH MBS1002PDH MBS1001PDH MBS1003PO5J MBS1002PO5J MBS1001PO5J MBS1003PO9J MBS1002PO9J MBS1001PO9J MBS1003PHJ MBS1002PHJ MBS1001PHJ MBS1003PFJ MBS1002PFJ MBS1001PFJ MBS1003PEJ MBS1002PEJ MBS1001PEJ MBS1003PDJ MBS1002PDJ MBS1001PDJ MBS1003PO5J7 MBS1002PO5J7 MBS1001PO5J7 MBS1003PO9J7 MBS1002PO9J7 MBS1001PO9J7 MBS1003PHJ7 MBS1002PHJ7 MBS1001PHJ7 MBS1003PFJ7 MBS1002PFJ7 MBS1001PFJ7 MBS1003PEJ7 MBS1002PEJ7 MBS1001PEJ7 MBS1003PDJ7 MBS1002PDJ7 MBS1001PDJ7
AB Series不锈钢粉末烧结滤芯型号：
AB3PO57H13 AB2PO57H13 AB1PO57H13 AB3PO97H13 AB2PO97H13 AB1PO97H13 AB3PH7H13 AB2PH7H13 AB1PH7H13 AB3PF7H13 AB2PF7H13 AB1PF7H13 AB3PE7H13 AB2PE7H13 AB1PE7H13 AB3PD7H13 AB2PD7H13 AB1PD7H13 AB3PO57H AB2PO57H AB1PO57H AB3PO97H AB2PO97H AB1PO97H AB3PH7H AB2PH7H AB1PH7H AB3PF7H AB2PF7H AB1PF7H AB3PE7H AB2PE7H AB1PE7H AB3PD7H AB2PD7H AB1PD7H AB3PO57J AB2PO57J AB1PO57J AB3PO97J AB2PO97J AB1PO97J AB3PH7J AB2PH7J AB1PH7J AB3PF7J AB2PF7J AB1PF7J AB3PE7J AB2PE7J AB1PE7J AB3PD7J AB2PD7J AB1PD7J AB3PO57J7 AB2PO57J7 AB1PO57J7 AB3PO97J7 AB2PO97J7 AB1PO97J7 AB3PH7J7 AB2PH7J7 AB1PH7J7 AB3PF7J7 AB2PF7J7 AB1PF7J7 AB3PE7J7 AB2PE7J7 AB1PE7J7 AB3PD7J7 AB2PD7J7 AB1PD7J7
Cylinder Series不锈钢粉末烧结滤芯2 3⁄8" Diameter Elements With 1" or 1 1⁄2" NPT(5)型号：
C-23-196PO5 C-23-186PO5 C-23-096PO5 C-23-066PO5 C-23-194PO5 C-23-184PO5 C-23-094PO5 C-23-064PO5 C-23-191PO5 C-23-181PO5 C-23-091PO5 C-23-061PO5 C-23-196PO9 C-23-186PO9 C-23-096PO9 C-23-066PO9 C-23-194PO9 C-23-184PO9 C-23-094PO9 C-23-064PO9 C-23-191PO9 C-23-181PO9 C-23-091PO9 C-23-061PO9 C-23-196PH C-23-186PH C-23-096PH C-23-066PH C-23-194PH C-23-184PH C-23-094PH C-23-064PH C-23-191PH C-23-181PH C-23-091PH C-23-061PH C-23-196PF C-23-186PF C-23-096PF C-23-066PF C-23-194PF C-23-184PF C-23-094PF C-23-064PF C-23-191PF C-23-181PF C-23-091PF C-23-061PF C-23-196PE C-23-186PE C-23-096PE C-23-066PE C-23-194PE C-23-184PE C-23-094PE C-23-064PE C-23-191PE C-23-181PE C-23-091PE C-23-061PE C-23-196PD C-23-186PD C-23-096PD C-23-066PD C-23-194PD C-23-184PD C-23-094PD C-23-064PD C-23-191PD C-23-181PD C-23-091PD C-23-061PD
Cylinder Series不锈钢粉末烧结滤芯1 1⁄2" Diameter Elements With 1⁄4" NPT(5)型号：
C-14-186PO5 C-14-096PO5 C-14-066PO5 C-14-184PO5 C-14-094PO5 C-14-064PO5 C-14-181PO5 C-14-091PO5 C-14-061PO5 C-14-186PO9 C-14-096PO9 C-14-066PO9 C-14-184PO9 C-14-094PO9 C-14-064PO9 C-14-181PO9 C-14-091PO9 C-14-061PO9 C-14-186PH C-14-096PH C-14-066PH C-14-184PH C-14-094PH C-14-064PH C-14-181PH C-14-091PH C-14-061PH C-14-186PF C-14-096PF C-14-066PF C-14-184PF C-14-094PF C-14-064PF C-14-181PF C-14-091PF C-14-061PF C-14-186PE C-14-096PE C-14-066PE C-14-184PE C-14-094PE C-14-064PE C-14-181PE C-14-091PE C-14-061PE C-14-186PD C-14-096PD C-14-066PD C-14-184PD C-14-094PD C-14-064PD C-14-181PD C-14-091PD C-14-061PD
