过滤精度：3微米/1微米/0.01微米/0.01微米
规格尺寸：齐全
产品描述：
滤芯概念：利用吸附式、凝聚式等过滤原理除去空气中的油、水等杂质的过滤设备材料，用于过滤器中。
主要构成:滤纸、骨架、海绵等
更换滤芯的注意事项：
1隔离过滤器，关闭进气阀或压缩空气供应系统，完全卸压后再关闭出气阀(或关闭有关阀后通过过滤器排水孔完全卸压)。
2拧掉壳体，取下旧滤芯。
3清洗过滤器壳体。
4换上新滤芯(不要遗漏密封圈，滤芯应装紧装正)
售前服务：提供技术咨询答疑、提供相应样本资料，进行技术交流；
售中服务：提供技术咨询答疑、提供相应图纸，进行技术交流；
售后服务：开机调试，产品维修。
相关滤芯型号：
24356677
24241838
24241879
24241937
24242000
24242067
24242125
24242190
24242257
24242299
24242331
24242372
24242414
24242455
24242497
24242539
24242570
24356669
24241812
24241861
24241929
24241986
24242059
24242117
24242174
24242240
24242281
24242323
24242364
24242406
24242448
24242489
24242521
24242562
24356685
24241846
24241895
24241952
24242018
24242083
24242141
24242208
24242265
24242307
24242349
24242380
24242422
24242463
24242505
24242547
24242588
24356693
24241853
24241903
24241960
24242034
24242091
24242166
24242224
24242273
24242315
24242356
24242398
24242430
24242471
24242513
24242554
24242596
| 型号 | 图号 |
处理气量 m³/min |
出/入口尺寸(mm) |
尺寸 H*W (mm) |
重量 kg |
| F42VG | 23705783 | 0.7 | 0.5’’BSPT | 225*89 | 0.9 |
| F42VH | 23705791 | ||||
| F42VD | 23705809 | ||||
| F42VA | 23705817 | ||||
| F72VG | 23705825 | 1.2 | 0.5’’BSPT | 225*89 | 0.9 |
| F72VH | 23705833 | ||||
| F72VD | 23705841 | ||||
| F72VA | 23705858 | ||||
| F108VG | 23705866 | 1.8 | 0.5’’BSPT | 258*89 | 1 |
| F108VH | 23705874 | ||||
| F108VD | 23705882 | ||||
| F108VA | 23705890 | ||||
| F216VG | 23705908 | 3.6 | 0.75’’BSPT | 333*120 | 2.4 |
| F216VH | 23705916 | ||||
| F216VD | 23705924 | ||||
| F216VA | 23705932 | ||||
| F294VG | 23705940 | 4.9 | 1’’BSPT | 432*120 | 2.9 |
| F294VH | 23705957 | ||||
| F294VD | 23705965 | ||||
| F294VA | 23705973 | ||||
| F342VG | 23705981 | 5.7 | 1’’BSPT | 432*120 | 2.9 |
| F342VH | 23705999 | ||||
| F342VD | 23706006 | ||||
| F342VA | 23706013 | ||||
| F390VG | 23706021 | 6.5 | 1.5’’BSPT | 432*120 | 3 |
| F390VH | 23706039 | ||||
| F390VD | 23706047 | ||||
| F390VA | 23706054 | ||||
| F444VG | 23706062 | 7.4 | 1.5’’BSPT | 432*120 | 3 |
| F444VH | 23706070 | ||||
| F444VD | 23706088 | ||||
| F444VA | 23706096 | ||||
| F540VG | 23706104 | 9 | 1.5’’BSPT | 432*120 | 3 |
| F540VH | 23706112 | ||||
| F540VD | 23706120 | ||||
| F540VA | 23706138 | ||||
| F690VG | 23706146 | 11.5 | 2’’BSPT | 521*162 | 5.1 |
| F690VH | 23706153 | ||||
| F690VD | 23706161 | ||||
| F690VA | 23706179 | ||||
| F810VG | 23706195 | 13.5 | 2’’BSPT | 521*162 | 5.1 |
| F810VH | 23706203 | ||||
| F810VD | 23706211 | ||||
| F810VA | 23706229 | ||||
| F990VG | 23706237 | 16.5 | 2’’BSPT | 845*160 | 6.5 |
| F990VH | 23706245 | ||||
| F990VD | 23706252 | ||||
| F990VA | 23706260 | ||||
| F1050VG | 23706278 | 17.5 | 2’’BSPT | 845*160 | 6.5 |
| F1050VH | 23706286 | ||||
| F1050VD | 23706294 | ||||
| F1050VA | 23706302 | ||||
| F1170VG | 23706310 | 19.5 | 2’’BSPT | 845*160 | 6.5 |
| F1170VH | 23706328 | ||||
| F1170VD | 23706336 | ||||
| F1170VA | 23706344 | ||||
| F1380VG | 23706351 | 23 | 2.5’’BSPT | 601*200 | 8.7 |
| F1380VH | 23706369 | ||||
| F1380VD | 23706377 | ||||
| F1380VA | 23706385 | ||||
| F1159VG | 23706393 | 26.5 | 2.5’’BSPT | 601*200 | 8.7 |
| F1159VH | 23706401 | ||||
| F1159VD | 23706419 | ||||
| F1159VA | 23706427 | ||||
| F1740VG | 23706435 | 29 | 2.5’’BSPT | 601*200 | 8.7 |
| F1740VH | 23706443 | ||||
| F1740VD | 23706450 | ||||
| F1740VA | 23706468 | ||||
| F2100VG | 23706476 | 35 | 3’’BSPT | 862*200 | 11 |
| F2100VH | 23706484 | ||||
| F2100VD | 23706492 | ||||
| F2100VA | 23706500 | ||||
| F2340VG | 23706518 | 39 | 3’’BSPT | 862*200 | 11 |
| F2340VH | 23706526 | ||||
| F2340VD | 23706534 | ||||
| F2340VA | 23706542 | ||||
| F2700VG | 23706559 | 15 | 4’’BSPT | 900*470 | 66 |
| F2700VH | 23706567 | ||||
| F2700VD | 23706575 | ||||
| F2700VA | 23706583 | ||||
| F3090VG | 23706591 | 51.5 | 5’’BSPT | 900*470 | 98 |
| F3090VH | 23706609 | ||||
| F3090VD | 23706617 | ||||
| F3090VA | 23706625 | ||||
| F3480VG | 23706633 | 58 | 5’’BSPT | 900*470 | 103 |
| F3480VH | 23706641 | ||||
| F3480VD | 23706658 | ||||
| F3480VA | 23706666 | ||||
| F4080VG | 23706674 | 68 | 5’’BSPT | 930*520 | 118 |
| F4080VH | 23706682 | ||||
| F4080VD | 23706690 | ||||
| F4080VA | 23706708 | ||||
| F4200VG | 23706716 | 70 | 5’’BSPT | 930*520 | 120 |
| F4200VH | 23706724 | ||||
| F4200VD | 23706732 | ||||
| F4200VA | 23706740 | ||||
| F4560VG | 23706757 | 76 | 5’’BSPT | 930*520 | 120 |
| F4560VH | 23706765 | ||||
| F4560VD | 23706773 | ||||
| F4560VA | 23706781 | ||||
| F4800VG | 23706799 | 80 | 6’’BSPT | 930*520 | 123 |
| F4800VH | 23706807 | ||||
| F4800VD | 23706815 | ||||
| F4800VA | 23706823 | ||||
| F5520VG | 23706831 | 92 | 6’’BSPT | 1020*580 | 125 |
| F5520VH | 23706849 | ||||
| F5520VD | 23706856 | ||||
| F5520VA | 23706872 | ||||
| F5940VG | 23706880 | 99 | 6’’BSPT | 1020*580 | 125 |
| F5940VH | 23706890 | ||||
| F5940VD | 23706906 | ||||
| F5940VA | 23706914 | ||||
| F7680VG | 23706922 | 128 | 6’’BSPT | 1020*580 | 148 |
| F7680VH | 23706930 | ||||
| F7680VD | 23706948 | ||||
| F7680VA | 23706955 | ||||
| F8700VG | 23706963 | 145 | 6’’BSPT | 1020*580 | 148 |
| F8700VH | 23706971 | ||||
| F8700VD | 23706989 | ||||
| F8700VA | 23706997 |
